Honda K24W5 2.4L Engine Gasoline Motor for Acura TLX Honda Accord Car Accesorios Auto parts Original Auto Engine Systems

In 2013, Honda began production of the updated K24W. It was an all-new 2.4L direct injection i-VTEC gasoline engine developed as part of Honda’s Earth Dreams next-generation engine series.

The K24W shares only the bore and stroke with previous K24 engines. The engine has a new die-cast aluminum cylinder block. A new forged steel crankshaft and lightweight pistons with cupped heads are inside the cylinder block. On top, the 2.4L Earth Dreams engine has a new lightweight die-cast aluminum cylinder head with 4 valves per cylinder, a high-pressure injector with intake valve ports, DOHC, i-VTEC, and an integrated exhaust manifold. The intake ports and combustion chambers have been optimized to improve the air-fuel mixture and combustion process. The intake and exhaust valves have a narrower angle of 35 degrees. The most noticeable external change is the reorientation of intake and exhaust. Now the air intake is facing back, and the exhaust is facing forward.

The intake and exhaust camshafts have an improved journal surface to reduce friction. They are driven by a silent chain with a friction-reducing double-lever tensioner. At the end of the exhaust camshaft is a direct injection high pressure fuel pump. This high pressure pump provides fuel pressure up to 20MPa for 6-stage injectors. To comply with the latest emissions regulations (California ULEV-2 and Federal Tier 2 Bin 5 certifications), the engine has been fitted with two high performance catalytic converters. The first converter is mounted directly on the cylinder head outlet, while the second is mounted slightly downstream of the engine.
